The following paragraphs, based on a Land platform, explain in further detail.
The Land platform AESP Category 711 comprises 5,468 pages. By halving this page count to cater for an illustration every other page and multiplying that half page
count by 20 listed items/parts/NSNs per page (based upon empirical data), it provided an estimated 2,734 pages to be processed with an estimated spared items
count of 54,680 items (2,734 X 20).
Further analysis following data upload into the Data Cleanse database, revealed that there are only 40,000 listed items; of which some items/parts/NSNs are used
multiple times (duplicate items).
Removing the duplicate items, to a single incidence of each, brought the number of individual items for checking against CSIS down to 16,709 individual items - a
69.4% reduction from the estimated 54,680 items as used in our initial assessment.
Note: We have defined a unique individual item as being a NSN and part number pairing and not just the NSN or just the part number.
The reduction in the number of items to check on the Land platform alone is provided for clarity in the table below:
Table 1 – Platform 1 Estimated Scope VS Accurate Item Count Analysis
Family Planning
Since Individual platforms also form part of a family of platforms from a single manufacturer, further efficiencies can be had by identifying common use
items/parts/NSNs across numerous platforms prior to conducting the CSIS check. This is tabled below by way of explanation:
Table 2 – 4 Platforms grouped as a Family Individual Items Count
Having loaded all four Platforms into the database we were able to identify common items and remove duplicate items to a single instance across all four platforms to
quantify the fleet’s total number of individual items to be checked against CSIS.
Table 3 – Combined Family Planning Scope Reduction
SUMMARY
To summarise, there are significant efficiency gains to be had using an accurate method of calculating the item count and therefore the scope of this task when
combining families of platforms/equipment. However, to arrive at an accurate scope and therefore cost, it does require up front work on behalf of TMS to undertake the
initial data verification, load and unique items analysis.
Based upon the initial calculations of the combined Platform fleet comprising 18,018 Parts Catalogue pages, half of which comprise 20 items per page (estimated
180,180 total number of items) we can reduce the scope of requirement to conduct the initial data verification, upload, CSIS check and the production of an Anomalies
Report from the initial anticipated item count of 180,180 items down to 36,776 items, a reduction of 79.5% in real terms to the overall scope of the combined Data
Cleanse task.
Note: The more information we can upload into the Data Cleanse capability, the less we will need to check CSIS for accuracy and further efficiency gains can be made.
ADDITIONAL OPTION CAPABILITY
In
addition
to
the
baseline
service—which
includes
data
receipt,
verification,
input,
and
a
single
CSIS
check
with
an
accompanying
Anomalies
Report
in
MS
Excel
format—TMS
offers
several
optional
capabilities.
These
include
the
provision
of
an
updated
Parts
Catalogue
in
electronic
file
format,
a
detailed
Consistency
Check
to
verify
preferred
MPN
selection,
and
the
Data
Interrogation
and
Reuse
service,
which
enables
cross-checking
and
alignment
with
stakeholder
systems.
Additional
services
also
include
the
conversion
of
PDF
documents
to
MS
Word
format
along
with
validation
of
the
output,
as
well
as
a
fully
Managed
Service
supported
by
a
dedicated web portal for client access and ongoing support.
